Toshiba VFS15-2037PM Inverter Drive
Product Description
The Toshiba VF-S15 VFS15-2037PM is a compact and high-performance variable frequency drive (VFD) designed for three-phase 200V motor control applications. Supporting motors up to 3.7kW, this inverter combines powerful torque performance, energy-saving operation, and user-friendly configuration in a compact design.
The VF-S15 Series features vector control technology for stable high-torque operation from startup to rated frequency. Its large setting dial enables quick parameter adjustments, while the built-in RS485 communication interface supports system integration and network expansion.
Designed with long-life components and an integrated noise filter, the inverter delivers reliable performance, reduced maintenance requirements, and improved operational efficiency across industrial automation applications.
Key Features
- Toshiba VF-S15 Series inverter drive
- Model: VFS15-2037PM
- Supports motors up to 3.7kW
- Three-phase 200V input
- Three-phase 200–240V output
- High-torque vector control operation
- Built-in noise filter
- RS485 communication interface
- Auto-tuning motor parameter setup
- Compact body design
- Removable terminal block
- Easy configuration and maintenance
- Energy-saving motor control technology
Product Specifications
| Item | Details |
|---|---|
| Brand | Toshiba |
| Model | VFS15-2037PM |
| Series | VF-S15 |
| Input Voltage | Three-Phase 200V |
| Output Voltage | Three-Phase 200–240V |
| Motor Capacity | 3.7 kW |
| Communication | RS485 |
| Noise Filter | Built-in Standard Filter |
| Control Method | Vector Control |
| Features | Auto-Tuning, High Torque, Compact Design |
Dimensions
| Unit | Size |
|---|---|
| mm | 140 × 150 × 170 mm |
| cm | 14 × 15 × 17 cm |
| inch | 5.51 × 5.91 × 6.69 in |
